MEAN WELL OWA60E12 Moistureproof Power Supply
The moistureproof power supply series provides 60W output with IP67 rating, suitable for damp, dust, and humidity environments. It features full-range universal input (90-264VAC), high efficiency up to 91%, and low no-load power consumption below 0.15W. Certified for safety standards EN 61558-2-16 and EN 60335-1, it supports protections against short circuit, overload, overvoltage, and overtemperature. The fanless design ensures reliable operation in harsh environments, making it ideal for household appliances, robotic lawn mowers, and other electronic devices requiring moisture and dust resistance.
MEAN WELL OWA60E12 Moistureproof Power Supply Specifications:
- Output Power: 60W
- Output Voltage Range: 12V, 15V, 20V, 24V, 30V, 36V, 42V, 48V, 54V
- Rated Current: 5A, 4A, 3A, 2A, 1.674A, 1.5A, 1.254A, 4.124A
- Ripple & Noise: Max. 150mVp-p to 350mVp-p depending on model
- Voltage Tolerance: ±4.0% to ±1.0%
- Line Regulation: ±1.0% to ±£1.0%
- Load Regulation: ±1.5% to ±1.0%
- Efficiency: Up to 91%
- Input Voltage Range: 90-264VAC
- Frequency Range: 47-63Hz
- Operating Temperature: -35°C to +70°C
- Dimensions: Approximately 130mm x 53mm x 35mm
- Class II power supply, no FG, fully isolated plastic case
- Certifications: EN61558-1, EN61558-2-16, EN60335-1, IP67 rated
- Protections: Short circuit, Overload, Overvoltage, Over temperature
- Cooling: Fanless, convection cooled
- MTBF: 292,800 hours
Buy the Buy Mean Well Moistureproof Power Supply Part Number OWA60E12 Online
Purchase the reliable moistureproof power supply online today. With IP67 rating, high efficiency up to 91%, and safety certifications, it is ideal for damp or dusty environments. Its universal input range from 90 to 264VAC makes it suitable for various applications, including household appliances and robotic lawn mowers. The fanless design ensures silent operation and durable performance in harsh conditions. Order now to benefit from fast delivery and guaranteed quality for your electronic needs.
Buy Mean Well OWA60E12 now and enjoy reliable, moistureproof performance for demanding environments with high efficiency and safety protections.
Frequently Asked Questions
Where can I buy MEAN WELL OWA60E12?
You can click on the BUY or RFQ button to purchase OWA60E12 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part OWA60E12?
You can download the OWA60E12 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of OWA60E12?
MEAN WELL
