MEAN WELL RSD60G12 Railway DC-DC Converter
The RSD-60G-12 is a 60W reliable railway DC-DC converter designed to operate within -40°C to +70°C temperatures, with high vibration and dust resistance for harsh environments. It features a wide input range of 9-36V DC, multiple output options including 12V, and compliance with EN50155 and EN45545-2 standards for fire and electrical safety. Its compact design with 25mm low profile, built-in protections such as over-voltage, over-current, and reverse polarity, and UL94V-0 casing make it suitable for railway, tram, metro systems, and industrial applications requiring high reliability and EMC performance.
MEAN WELL RSD60G12 Railway DC-DC Converter Specifications:
- Input Voltage Range: 9-36V DC / 18-72V DC / 40-160V DC options
- Output Voltage Options: 3.3V, 5V, 12V, 24V
- Rated Power: 60W
- Ripple & Noise: 50-100mVp-p depending on model
- Voltage Tolerance: ±2.0%
- Line Regulation: 0.2-0.5%
- Load Regulation: 0.2-0.5%
- Efficiency: Up to 92.5%
- Working Temperature: -40°C to +70°C with external mounting
- Isolation Voltage: 4000VDC input/output
- Protection: Short circuit, Overload, Over voltage, Reverse polarity
- Dimensions: 128mm x 60mm x 25mm
- Humidity: 5% to 95% RH non-condensing
- Vibration: IEC61373 compliant, 5G at 10-500Hz
- Safety Standards: IEC60950-1, EN50155, EN45545-2
- MTBF: 593,800 hours at 25°C
Buy the Mean Well RSD-60G-12 – Reliable Railway DC-DC Converter for Industrial Applications
Purchase the reliable railway DC-DC converter from Mean Well online today. Designed for harsh environments, it offers wide input ranges, multiple output options, and EMC compliance for transportation and industrial systems. Whether for railways, trams, or industrial applications, this compact and rugged converter ensures secure power regulation, built-in protections, and long-term performance, making it the ideal choice for demanding applications. Accelerate your project timeline by ordering now and enjoy seamless installation and dependable operation.
Buy Mean Well RSD-60G-12 now and experience unmatched reliability, exceptional performance in harsh railway environments, and industry-leading safety features.
