MEAN WELL RSD60L33 railway DC-DC converter
The RSD-60L-3.3 is a reliable 60W railway DC-DC converter designed for transportation and industrial systems operating in harsh environments. Compliant with EN50155 and EN45545-2 standards, it features a wide input range of 40-160V DC, low ripple and noise, high EMC performance, and a compact 25mm low profile enclosure. Suitable for train, tram, and bus applications, it withstands extreme temperatures from -40°C to +70°C, vibrations, and dust, ensuring stable operation with protections against short circuit, overload, and overvoltage. Ideal for industrial control, telecom, and datacom systems requiring robust and efficient power supply solutions.
MEAN WELL RSD60L33 railway DC-DC converter Specifications:
- Power Rating: 60W
- Input Voltage Range: 40~160V DC
- Output Voltage: 3.3V
- Output Current: 0~12A
- Ripple & Noise: Max. 100mVp-p
- Voltage Tolerance: ±2.0%
- Line Regulation: 0.5%
- Load Regulation: 0.5%
- Efficiency (Typ.): 87%
- Operating Temperature: -40°C to +70°C
- Storage Temperature: -40°C to +85°C
- Humidity: 5~95% RH non-condensing
- Isolation Resistance: 100 MΩ/500VDC
- Dimensions: 128mm x 60mm x 25mm
- Safety Standards: IEC60950-1, EN45545-2
- Vibration Resistance: 10~500Hz, 5G
Buy the Mean Well RSD-60L-3.3 – Reliable Railway Power Module for Industrial Applications
Purchase the Mean Well RSD-60L-3.3 railway DC-DC converter online today and ensure your transportation or industrial systems operate reliably in extreme conditions. This 60-watt power supply meets strict EN50155 and EN45545-2 standards, offering a wide input range of 40-160V for flexible applications. Its rugged design withstands -40°C to +70°C temperatures, high vibration, and dust, providing stable output with low ripple and noise. With built-in protections and a compact form factor, it’s ideal for control, telecom, and datacom systems requiring resilient power solutions.
Buy Mean Well RSD-60L-3.3 now and experience unmatched reliability and performance in harsh industrial environments and transportation systems.
Frequently Asked Questions
Where can I buy MEAN WELL RSD60L33?
You can click on the BUY or RFQ button to purchase RSD60L33 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part RSD60L33?
You can download the RSD60L33 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of RSD60L33?
MEAN WELL
