MEAN WELL SD100D5 industrial power converter
The SD-100D-5 is a 100W single output DC-DC power converter designed for industrial applications, offering a wide input range of 72V to 144V DC. It features built-in EMI filter, low ripple noise, and protections against short circuit, overload, and overvoltage. With high reliability, a two-year warranty, and compliance with IEC safety standards, it ensures stable performance in demanding environments. Its compact size and efficient design make it suitable for automation, control systems, and industrial equipment requiring robust power solutions.
MEAN WELL SD100D5 industrial power converter Specifications:
- Power Rating: 100W
- Input Voltage Range: 72~144VDC
- Output Voltage: 5V
- Rated Current: 18A
- Ripple & Noise: Max. 100mVp-p
- Voltage Tolerance: ±2.0%
- Line Regulation: 0.5%
- Load Regulation: 0.5%
- Efficiency: Up to 83%
- Protections: Short circuit, Overload, Overvoltage (Hiccup mode)
- Isolation: 1500VAC I/O
- Operating Temp: -15°C to +60°C (SD-100A), -10°C to +60°C (SD-100B/C/D)
- Humidity: 20% to 90% RH non-condensing
- Dimensions: 199mm x 98mm x 38mm
- Certifications: IEC60950-1, CB, EAC TP TC 004
- MTBF: Minimum 341.9K hours
Buy the MW SD-100D-5 – Reliable Power Converter for Industrial Applications
Purchase MW SD-100D-5 online today for reliable and efficient power delivery in automation and industrial control systems. Its wide input range, high efficiency, and protection features ensure long-lasting performance with minimal maintenance. Ideal for demanding environments, this compact power converter meets all safety and EMI standards, providing peace of mind and seamless integration into your equipment. Order now to optimize your operation with industry-grade power solutions designed for durability and consistent performance in diverse industrial applications.
Get MW SD-100D-5 today—built for precision, high durability, and for powering industrial automation systems with stable voltage output.
Frequently Asked Questions
Where can I buy MEAN WELL SD100D5?
You can click on the BUY or RFQ button to purchase SD100D5 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part SD100D5?
You can download the SD100D5 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of SD100D5?
MEAN WELL
