MEAN WELL SD15A12 DC-DC Converter
The SD-15A-12 is a 15W single output DC-DC converter designed for reliable power conversion in industrial applications. Featuring a wide input voltage range and high efficiency, it offers a stable 12V output with low ripple noise and comprehensive protections including overload, over voltage, and short circuit. Its compact size and built-in EMI filter make it suitable for various electronic systems, ensuring durability and safety under harsh environments. Ideal for automation, instrumentation, and communication equipment requiring stable and efficient power supply.
MEAN WELL SD15A12 DC-DC Converter Specifications:
- Power: 15W
- Input Voltage Range: 92~18VDC (A), 18~36VDC (B), 36~72VDC (C)
- Output Voltage: 12V ±2.0% with regulation of ±0.5%
- Output Ripple & Noise: Max. 120mVp-p
- Efficiency: 68% (typical)
- Current Range: 0~1.25A
- Over Load Protection: 105~160% rated output
- Protection Type: Hiccup mode, auto recovery
- Over Voltage Protection: 13.8V-16.2V
- Working Temperature: -10°C to +60°C
- Humidity: 20-90% RH non-condensing
- Dimensions: 78mm x 51mm x 28mm
- Isolation Voltage: Up to 1kV
- MTBF: Approx. 652,500 hours
- Compliance: EN55022, EN61000-4-2/3/4/6/8/24
Buy the Buy Mean Well DC-DC Converter Part Number SD15A12 Online
Enhance your electronic systems with the high-performance SD15A12 DC-DC converter. Crafted for durability and efficiency, it provides a stable 12V output from a wide input range, ideal for automation, instrumentation, and communication devices. Featuring low ripple noise, extensive protection features including overload and over voltage, this compact power supply ensures safety and reliability in harsh environments. Easy to install and compliant with international standards, it is the perfect choice for demanding industrial applications, delivering consistent, dependable power when you need it most.
Order your Mean Well Series SD15A12 compact power supply today and ensure stable, reliable power for your industrial or automation projects.
Frequently Asked Questions
Where can I buy MEAN WELL SD15A12?
You can click on the BUY or RFQ button to purchase SD15A12 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part SD15A12?
You can download the SD15A12 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of SD15A12?
MEAN WELL
