MOLEX 09501071 SPOX Crimp Housing
The MOLEX 09-50-1071 is a SPOX Crimp Housing within the 5195 series, engineered for reliable wire-to-board connections. This housing offers a 3.96mm pitch and accommodates a maximum of 7 circuits. Constructed from durable nylon, it provides excellent insulation and mechanical strength. Its friction ramp design simplifies assembly, while its compact size makes it ideal for space-constrained applications. The housing is RoHS compliant and operates effectively within a temperature range of -40°C to +105°C, making it suitable for a wide range of industrial and commercial environments. It is designed to mate with 5272, 5273, 5274, 5096, 53405, and 5271 series connectors.
MOLEX 09501071 SPOX Crimp Housing Specifications:
- status: Active
- overview: SPOX Connector System
- description: 3.96mm Pitch SPOX Crimp Housing, Female, with Friction Ramp, 7 Circuits, Natural
- product_family: Crimp Housings
- series: 5195
- application: Signal, Wire-to-Board
- upc: 800753640719
- circuits_maximum: 7
- color_resin: Natural
- flammability: 94V-2
- gender: Receptacle
- glow_wire_capable: No
- material_resin: Nylon
- net_weight: 1988.600/mg
- number_of_rows: 1
- packaging_type: Bag
- panel_mount: No
- pitch_mating_interface: 3.96mm
- pitch_termination_interface: 3.96mm
- stackable: No
- temperature_range_operating: -40°C to +105°C
- engineering_number: 5195-07
- drawing_numbers: SD-5195-N
- elv: Not Relevant
- rohs: Compliant
- reach_svhc: Not Contained
- halogen_free_status: Low-Halogen
- mates_with: 5272, 5273, 5274, 5096, 53405, 5271
- uses_with: 5194, 5225
