MOLEX 10085121 Power Header Connector
The KK Header Vertical with Polarizing Backwall is a reliable power connector designed for wire-to-board applications. It features 12 circuits with tin plating on brass contacts, offering durability up to 94 mating cycles. Built from nylon resin, it operates within a temperature range of -55°C to +105°C, with a maximum voltage of 250V and current of 7A per contact. Its 5.08mm pitch ensures precise mating, while the vertical orientation facilitates PCB mounting. Meets RoHS, UL, and halogen-free standards, ideal for industrial power and electronic assemblies.
MOLEX 10085121 Power Header Connector Specifications:
- Number of Circuits: 12
- Color - Resin: Natural
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Nylon
- Net Weight: 3.260 grams
- Orientation: Vertical
- PC Tail Length: 25mm
- PCB Thickness - Recommended: 1.60mm
- Temperature Range - Operating: -55°C to +105°C
- Voltage - Maximum: 250V
- Current - Maximum per Contact: 7A
- Pitch - Mating Interface: 5.08mm
- Flammability: UL 94V-2
- RoHS Compliance: Yes
- Halogen-Free: Yes
- Surface Mount Compatible: No
- Shrouded: No
- Stackable: No
- Durability (mating cycles max): 94
Buy the Molex 0010085121 – Reliable Power Connector for Industrial Applications
Discover the Molex Power Header Connector, featuring 12 circuits with tin-plated brass contacts encased in durable nylon resin. This vertical connector offers a 5.08mm pitch, ensuring precise PCB mounting for industrial power applications. Rated for 250V and 7A per contact, it supports up to 94 mating cycles and meets UL, RoHS, and halogen-free standards. Its compact design and reliable performance make it ideal for automation, industrial electronics, and power distribution systems, providing a secure and durable connection for critical electrical assemblies.
Buy Molex 0010085121 now and experience unmatched reliability and performance in industrial power connections.
Frequently Asked Questions
Where can I buy MOLEX 10085121?
You can click on the BUY or RFQ button to purchase 10085121 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 10085121?
You can download the 10085121 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 10085121?
MOLEX
