MOLEX 10321061 Wire-to-Board Connector
The Molex SPOX Wire-to-Board Header is a 5.08mm pitch connector featuring a vertical orientation with friction lock, designed for reliable wire-to-board connections in electronic assemblies. It supports up to 6 circuits, with durable construction rated for up to 30 mating cycles, and is compliant with RoHS, UL, and CSA standards. Made from brass with tin plating, the connector operates within a temperature range of -40°C to +105°C. It offers easy PCB mounting, with a 3.60mm PCB tail length and high current capacity of 7.0A per contact, suitable for various industrial and electronic applications.
MOLEX 10321061 Wire-to-Board Connector Specifications:
- Pitch: 5.08mm
- Number of Circuits: 6
- Current per Contact: 7.0A
- Voltage Maximum: 250V
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Nylon
- Color - Resin: Natural
- Durability: 30 mating cycles
- Operating Temperature Range: -40°C to +105°C
- PCB Tail Length: 3.60mm
- PC Board Thickness - Recommended: 1.60mm
- Flammability: 94V-2
- RoHS Compliance: Yes
- UL & CSA Certified: Yes
- Orientation: Vertical
- Termination Interface: Through Hole
- Packaging: Bag
Buy the Buy Molex Wire-to-Board Connector Part Number 0010321061 Online
Purchase the Molex Wire-to-Board Connector online for high-performance, reliable connections in electronic devices. Made from durable materials with a robust design, this connector features a 5.08mm pitch and supports up to 6 circuits. It is RoHS compliant, UL and CSA certified, and designed for easy PCB mounting with a 3.60mm tail length. Ideal for industrial, automation, and electronic automation systems, this connector ensures long-lasting performance and safety, accommodating operating temperatures from -40°C to +105°C, making it an essential component for modern electronic solutions.
Get Molex 0010321061 today—built for reliable, high-current connections in electronic and industrial applications.
