MOLEX 1053091105 Nano-Fit Vertical Header
The MOLEX 1053091105 Nano-Fit Vertical Header is a compact and reliable connector solution for power applications. Designed with a 2.50mm pitch and a single-row configuration, it accommodates 5 circuits, making it ideal for various wire-to-board connections in consumer electronics, industrial equipment, and automotive systems. The header's kinked pins simplify insertion, while the tin plating ensures excellent solderability and corrosion resistance. Its glow-wire compliance and robust construction contribute to its suitability for demanding environments. It is part of the Nano-Fit Power Connectors series and is RoHS compliant.
MOLEX 1053091105 Nano-Fit Vertical Header Specifications:
- Overview: Nano-Fit Power Connectors
- Description: Nano-Fit Vertical Header, Through Hole, 2.50mm Pitch, Single Row, 5 Circuits, with Kinked Pins, Tin (Sn) Plating, Black, Glow-Wire Capable, Tray
- Status: Active
- Circuits (Loaded): 5
- Circuits (maximum): 5
- Color - Resin: Black
- Durability (mating cycles max): 25
- Flammability: 94V-0
- Glow-Wire Capable: Yes
- Mates With: Nano-Fit Receptacle Housing 1053071205
- Keying to Mating Part: Yes
- Lock to Mating Part: Yes
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Liquid Crystal Polymer
- Net Weight: 0.570/g
- Number of Rows: 1
- Orientation: Vertical
- PC Tail Length: 3.20mm
- PCB Locator: Yes
- PCB Retention: Yes
- PCB Thickness - Recommended: 1.60mm, 2.40mm
- Pitch - Mating Interface: 2.50mm
- Pitch - Termination Interface: 2.50mm
- Plating min - Mating: 1.524µm
- Plating min - Termination: 1.524µm
- Polarized to Mating Part: Yes
- Polarized to PCB: Yes
- Shrouded: Yes
- Stackable: No
- Surface Mount Compatible (SMC): No
- Temperature Range - Operating: -40° to +105°C
- Termination Interface: Style: Through Hole
- Current - Maximum per Contact: 8.0A
- Voltage - Maximum: 250V AC (RMS)/DC
- Application: Power, Wire-to-Board
- Halogen-Free: Yes
- Packaging Type: Tray
- UPC: 887191937397
- REACH SVHC: Not Contained
- RoHS Phthalates: Not Contained
