MOLEX 901361215 Interconnect System
The C-Grid III interconnection system provides a flexible, modular, and reliable solution for electronic packaging in industrial, automotive, and consumer electronics. Featuring 15 circuits, fully shrouded, and compatible with 0.64mm square pins, it supports wire-to-board and board-to-board connections. Designed with 0.381um gold plating for durability, it meets glow wire requirements and industry standards like DIN41651. Capable of operating -55°C to +125°C, it ensures high performance in demanding environments and offers easy assembly with through hole termination and vertical orientation for efficient PCB integration.
MOLEX 901361215 Interconnect System Specifications:
- Number of Circuits: 15
- Circuits (Maximum): 15
- Color - Resin: Black
- Material - Metal: Brass
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- Pin Compatibility: 0.64mm square pins
- Pitch - Mating Interface: 2.54mm
- Pitch - Termination Interface: 2.54mm
- Plating min - Mating: 0.381um Au
- Plating min - Termination: 3.048um
- Temperature Range - Operating: -55°C to +125°C
- Current - Max per Contact: 3.0A
- Voltage - Max: 350V AC/DC
- Termination Style: Through Hole
- Orientation: Vertical
- Net Weight: 2.152g
- Packaging: Tray
- Flammability: UL 94V-0
- Glow-Wire Capable: No
Buy the Molex 90136-1215 – Reliable Interconnection System for Industrial Applications
Experience the reliable and versatile interconnection solution with the Molex interconnect system. Designed for industrial, automotive, and consumer electronics, it features 15 circuits with gold-plated contacts for durability, operating effectively from -55°C to +125°C. Fully compliant with industry standards like DIN41651, it supports wire-to-board and board-to-board connections, ensuring secure and robust electronic assemblies. Engineered for easy installation with through hole termination, making it ideal for high-performance industrial applications and demanding environments.
Get Molex 90136-1215 today—built for precision, high performance, and long-lasting durability in demanding environments.
Frequently Asked Questions
Where can I buy MOLEX 901361215?
You can click on the BUY or RFQ button to purchase 901361215 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 901361215?
You can download the 901361215 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 901361215?
MOLEX
