MOLEX 395000506 Eurostyle Terminal Blocks
The Eurostyle Terminal Blocks are 3.50mm pitch pluggable connectors designed for reliable electrical connections in industrial applications. They feature gold-plated contacts for corrosion resistance, support 6 circuits in a horizontal orientation, and are suitable for operating temperatures from -40°C to +105°C. These terminal blocks accommodate wire sizes from 16 to 30 AWG with a maximum current of 8A and voltage of 300V. They comply with RoHS, low-halogen, and UL certifications, making them ideal for control panels and automation systems.
MOLEX 395000506 Eurostyle Terminal Blocks Specifications:
- Pitch: 3.50mm between contacts
- Number of Circuits: 6
- Orientation: Horizontal
- Entry Angle: Vertical
- Temperature Range: -40°C to +105°C
- Wire Size: 16-30 AWG (0.05-1.50 mm²)
- Maximum Current: 8.0A per contact
- Maximum Voltage: 300V
- Material: Gold-plated contacts, durable insulator
- Certifications: UL, RoHS, Low-Halogen
- Dimensions: Standard Eurostyle footprint, specific dimensions vary
- Application: Industrial control panels, automation systems, PCB connections
Buy the Molex 395000506 – Reliable Eurostyle Terminal Blocks for Industrial Applications
Secure your industrial electrical connections with Molex Eurostyle Terminal Blocks. Designed for durability and precision, these 3.50mm pitch terminal blocks support 6 circuits, feature gold plating for corrosion resistance, and operate efficiently from -40°C to +105°C. Certified UL and RoHS compliant, they ensure safety and environmental standards. Easy to install, compatible with multiple wire sizes from 16 to 30 AWG, and ideal for automation, control panels, and PCB applications. Get yours online today for reliable performance.
Buy Molex 395000506 now and experience unmatched reliability and performance in your industrial connections.
Frequently Asked Questions
Where can I buy MOLEX 395000506?
You can click on the BUY or RFQ button to purchase 395000506 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 395000506?
You can download the 395000506 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 395000506?
MOLEX
