MOLEX 1200660374 Industrial M12 Connector
The Micro-Change M12 double-ended cordset features 4 poles with female 90° and male straight connectors, utilizing TPE cable that measures 0.50 meters in length. Designed for industrial applications, it offers IP67 dust and water resistance, made with nickel-plated brass contacts and TPU cable jacket for durability. Certification includes UL and CSA, and it operates within a temperature range of -20°C to +105°C at 4A and 250V. Ideal for automation and control systems needing reliable, quick-connect M12 connectors.
MOLEX 1200660374 Industrial M12 Connector Specifications:
- Product Family: Micro-Change (M12)
- Connector End A: Female (90°)
- Connector End B: Male (Straight)
- Poles: 4
- IP Rating: IP67
- Material - Contact: Nickel-plated Brass
- Material - Cable Jacket: TPE
- Cable Diameter: 5.30mm (.209")
- Cable Length: 0.50m (1.64')
- Color - Cable Jacket: Yellow
- Coupling Style: Threaded
- Net Weight: 54.620 g
- Temperature Range - Operating: -20°C to +105°C
- Wire Size AWG: 22
- Current - Maximum per Contact: 4.0A
- Voltage - Maximum: 250V AC/DC
- Standards: UL, CSA
Buy the Molex Series Micro-Change M12: 1200660374
Enhance your industrial automation and control systems with this high-quality M12 connector cordset by Molex. Featuring IP67 protection, durable nickel-plated brass contacts, and TPE cable for flexibility. Its 0.50-meter length and threaded coupling style provide secure and quick connections in demanding environments. Certified by UL and CSA, it operates efficiently within a wide temperature range. Ideal for automation, robotics, and manufacturing applications requiring robust, reliable, and easy-to-install connectors.
Order your Molex Series Micro-Change M12 1200660374 today and ensure reliable connectivity for your industrial automation projects.
