MOLEX 1200660378 Industrial Cordset
This Micro-Change M12 double-ended cordset features 4 poles with female 90° and straight male connectors, constructed with TPE cable rated IP67. It includes a 2.0-meter yellow cable suitable for industrial environments, offering reliable power and signal transmission. The connectors are made of nickel-plated brass with fluoro-elastomer O-rings, ensuring durability and environmental resistance. Certified for UL and CSA standards, this cordset operates within -20°C to +105°C, supporting up to 4A and 250V. Ideal for automation, sensors, and industrial control applications, it provides robust, sealed connections for demanding environments.
MOLEX 1200660378 Industrial Cordset Specifications:
- Connector Type: Micro-Change (M12), double-ended, 4 poles
- Connector End A: Female 90°
- Connector End B: Male Straight
- Cable Length: 2.0 meters
- Cable Diameter: 5.30 mm (.209 inches)
- Cable Material: TPE, Yellow
- Cable Jacket Material: TPE
- Connector Body Material: Nickel-plated Brass
- O-Ring Material: Fluoro-elastomer
- IP Rating: IP67
- Operating Temperature Range: -20°C to +105°C
- Current Rating per Contact: 4A
- Voltage Rating: 250V AC/DC
- Wire Size AWG: 22
- Agency Certifications: UL, CSA
- RoHS & ELV Compliant, Halogen-Free, Exemption 6(c), REACH SVHC
- Net Weight: Approximately 115.170 grams
- Color: Yellow
- Coupling Style: Threaded
- Gender: Female (End A), Male (End B)
Buy the Molex 1200660378 – Reliable M12 Industrial Cordset for Automation Applications
Enhance your automation system with the Molex 1200660378 industrial cordset. Featuring IP67-rated sealing, 4 poles, and a robust TPE cable, it ensures reliable power and signal transfer in harsh environments. The 2-meter yellow cable comes with powder-coated nickel-plated brass connectors, designed for durability and corrosion resistance. Suitable for sensors, control panels, and automation equipment, this cordset offers easy installation, excellent environmental sealing, and compliance with UL and CSA standards, making it the ideal choice for demanding industrial applications.
Buy Molex 1200660378 now and experience unmatched reliability and performance in industrial automation with durable, sealed connections.
Frequently Asked Questions
Where can I buy MOLEX 1200660378?
You can click on the BUY or RFQ button to purchase 1200660378 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 1200660378?
You can download the 1200660378 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 1200660378?
MOLEX
