MOLEX 1510878101 Single-Row Connector
The MOLEX 1510878101 Milli-Grid Single-Row Connector is a versatile solution for signal configurations in data communication, consumer electronics, and computing applications. Its shrouded single-row design provides terminal protection and space savings, while the integral positive lock ensures secure mating and easy unmating. Available with different solder tail lengths, this connector accommodates PCBs of varying thicknesses. It is designed with a wide latch-pad surface for easy unmating and includes a retention peg for secure PCB mounting. Applications include data communications, telecommunications, high-end computing, personal computers, refrigerators, and washing machines.
MOLEX 1510878101 Single-Row Connector Specifications:
- Packaging: Tube (Header), Bulk (Crimp Header & Receptacle)
- UL File No.: E29179
- CSA File No.: 1585720 (LR 19980)
- Mates With: 151062/63/64/65 with 151100 housing, 151098 with 151100 housing
- Use With: 151100 housing with 50394 terminals, 151098 housing with 151087 terminals
- Terminal Used: Copper Alloy
- Designed In: Millimeters
- Halogen Free: Yes
- Glow Wire Compliant: No
- Voltage (max.): 125VAC
- Current (max.): 2.5A
- Low Level Contact Resistance: 30 milliohms (5 milliohms Crimp terminal)
- Insulation Resistance: 1000 Megohms
- Contact Insertion Force: 35N max. (latch engaged), 3.5N per circuit max (latch disengaged)
- Contact Retention to Housing: 45N min. (latch engaged), 0.3N per circuit min. (latch disengaged)
- Peg Insertion Force in PCB: 35 to 45N
- Peg Retention Force in PCB: 5N min.
- Durability (min.): 50 cycles (Gold-plated), 25 cycles (Tin-plated)
- Housing (Header): LCP, Glass-filled, UL94V-0, Black
- Housing (Crimp Receptacle): PBT, UL94V-0, Black
- Housing (Crimp Header): PBT, Glass-filled, UL94V-0, Black
- Contact: Copper Alloy
- Plating Contact Area: Refer to table
- Plating Solder Tail Area: 2.00µm Matte Tin (Sn) Underplating: 1.25µm Nickel (Ni)
- Operating Temperature: -40 to +70°C
