MOLEX 151321205 Pico-Lock Cable Assembly
The Pico-Lock connector system offers a reliable and efficient connection solution for various electronic applications. Featuring a 1.50mm pitch and 12 circuits, this dual-ended cable assembly measures 450mm in length and is made of high-temperature thermoplastic with copper alloy contacts plated in gold and tin. Suitable for a maximum voltage of 150V, it ensures secure mating with features like lock to mating part. This black cable assembly is ideal for applications requiring a durable, RoHS-compliant connector with precise wire insulation and crimp or compression termination interfaces.
MOLEX 151321205 Pico-Lock Cable Assembly Specifications:
- Cable Length: 450.00mm
- Circuits: 12
- Color: Black
- Gender: Female-Female
- Lock to Mating Part: Yes
- Material - Metal: Copper Alloy
- Material - Plating: Mating Gold, Tin
- Material - Resin: High Temperature Thermoplastic
- Pitch - Mating Interface: 1.50mm
- Wire Insulation Diameter: 1.10mm
- Wire Size: AWG 24
- Voltage - Maximum: 150V
Buy the Molex 151321205 – Reliable Pico-Lock Connectors for Industrial Applications
Purchase your Molex Pico-Lock cable assembly online today and experience reliable, high-performance connections for your electronic projects. Featuring a 1.50mm pitch, 12 circuits, and a 450mm length, this RoHS-compliant connector ensures secure and durable performance. Made with high-temperature thermoplastic and plated copper alloy contacts, it is suitable for applications requiring a maximum voltage of 150V. Easy to install with crimp or compression termination interfaces, this assembly offers excellent electrical conductivity and mechanical stability for industrial and electronic uses.
Order your Molex Series15132 Pico-Lock cable assembly today and enhance your projects with dependable, high-quality electrical connections.
