MOLEX 151670721 Premo-Flex FFC Jumper
The MOLEX 15167-0721 Premo-Flex FFC jumper is a flexible flat cable connector designed for connecting flexible circuits. It offers a 1.00mm pitch, 4 circuits, and tin plating for reliable signal transmission. With a 305.00mm cable length, it's suitable for various applications requiring a flexible and compact connection solution. This jumper is ideal for applications in consumer electronics, automotive, and industrial equipment where space is limited and flexibility is required.
MOLEX 151670721 Premo-Flex FFC Jumper Specifications:
- Part Number: 0151670721
- Status: Active
- Overview: Premo-Flex Cable Jumpers
- Description: 1.00mm Pitch Premo-Flex FFC Jumper, Same Side Contacts (Type A), 305.00mm Cable Length, Tin (Sn) Plating, 4 Circuits
- Product Family: Cable
- Series: 15167
- Comments: Contacts on the same side, Type A
- Cable Length: 305.00mm
- Circuits (Loaded): 4
- Material - Plating Mating: Tin
- Net Weight: 1.000/g
- Packaging Type: Bag
- Pitch - Mating Interface: 1.00mm
- Temperature Range - Operating: -40° to +105°C
- Current - Maximum per Contact: 1.2A
- Voltage - Maximum: 60V AC
- EU ELV: Not Relevant
- EU RoHS: Compliant
- REACH SVHC: Not Contained
- Halogen-Free Status: Not Low-Halogen
- RoHS Phthalates: Not Contained
- UPC: 884982855038
- Mates With: Easy-On FFC/FPC Connector: 522070433, 522710479
