MOLEX 1720650310 Mega-Fit Power Header
The Mega-Fit Slim Vertical Header is a durable, high-current wire-to-board power connector designed for reliable electrical connections in industrial and electronic applications. Featuring a 5.70mm pitch, dual-row configuration, and 10 circuits, it is gold-plated for excellent conductivity and corrosion resistance. The through-hole design supports high mating cycle durability and is glow-wire capable, ensuring safety compliance. Made from high-performance liquid crystal polymer with high conductivity copper, it supports operating temperatures from -40°C to +120°C. Suitable for power distribution in complex electronic systems, its compact size allows easy integration into various assemblies.
MOLEX 1720650310 Mega-Fit Power Header Specifications:
- Number of Circuits: 10
- Pitch: 5.70mm
- Material - Metal: High Conductivity Copper
- Plating - Mating: 0.76um Gold
- Plating - Termination: Matte Tin
- Material - Resin: Liquid Crystal Polymer
- Operating Temperature Range: -40°C to +120°C
- Mated Height: 14.80mm
- Maximum Mating Cycles: 50
- Voltage Rating: 600V AC/DC
- Current per Contact: 23.0A
- Orientation: Vertical
- First Mate / Last Break: Yes
- Glow-Wire Capable: Yes
- Color - Resin: Black
- Installation Type: Through Hole
- Surface Mount Compatible: No
- RoHS: Compliant
- Product Weight: 5.574 grams
Buy the Buy Molex Mega-Fit Power Connectors Part Number 1720650310 Online
Purchase the Molex Mega-Fit Power Header 1720650310 online for reliable power connectivity in industrial, automation, and electronic applications. Designed with a 5.70mm pitch, dual-row configuration, and 10 circuits, it ensures efficient current handling up to 23A per contact at 600V. Made from high-quality high conductivity copper and durable liquid crystal polymer, it withstands temperatures from -40°C to +120°C. Gold-plated contacts enhance conductivity and corrosion resistance. Its glow-wire capability promotes safety compliance, making it ideal for complex electronic power distribution systems requiring robust, compact, and safe connections.
Get Molex Mega-Fit Power Connectors 1720650310 today—built for high-current power distribution in demanding electronic systems.
Frequently Asked Questions
Where can I buy MOLEX 1720650310?
You can click on the BUY or RFQ button to purchase 1720650310 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 1720650310?
You can download the 1720650310 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 1720650310?
MOLEX
