MOLEX 190380011 InsulKrimp Snap Plug Receptacle
The MOLEX 19038-0011 InsulKrimp snap plug receptacle is a robust and reliable connector designed for quick and easy termination of 14-16 AWG wires. Its closed barrel construction provides a secure connection, while the blue PVC insulation offers excellent insulation and protection. Commonly used in automotive, industrial, and consumer electronics applications, this receptacle ensures a dependable electrical connection. It is compatible with various tooling options for efficient and consistent crimping, making it a versatile choice for a wide range of applications.
MOLEX 190380011 InsulKrimp Snap Plug Receptacle Specifications:
- Overview: Snap Plugs and Receptacles
- Description: InsulKrimp Snap Plug Receptacle for 14-16 AWG Wire, PVC, Fits Male Plug Diameter 4.57mm
- Product Family: Quick Disconnects
- Series: 19038
- Comments: Fits Male Plug Dia. 4.57mm
- Crimp Quality Equipment: Yes
- Insulated: Fully
- Type: Snap Receptacle
- UPC: 800753048782
- Barrel Type: Closed
- Color - Resin: Blue
- Flammability: 94V-0
- Gender: Female
- Glow-Wire Capable: No
- Insulation: PVC
- Lock to Mating Part: None
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: PVC
- Net Weight: 1.248/g
- Orientation: Straight
- Packaging Type: Bag
- Termination Interface Style: Crimp or Compression
- Wire Insulation Diameter: 3.81mm max.
- Wire Size AWG: 14, 16
- Wire Size mm²: 1.00-2.50
- Voltage - Maximum: 600V
- Engineering Number: BRB-2180
- EU ELV: Not Relevant
- EU RoHS: Not Reviewed
- REACH SVHC: Not Contained
- Halogen-Free Status: Not Low-Halogen
- RoHS Phthalates: Not Contained
- Agency Certification CSA: LR18689
- Agency Certification UL: E152602
