MOLEX 191980047 Avikrimp Spade Terminal
The MOLEX 19198-0047 Avikrimp Spade Tongue Terminal is a solderless termination solution for connecting wires to various devices. Designed for 10-12 AWG wire, this terminal offers a secure and reliable connection with its closed barrel design and tin plating. The nylon insulation provides excellent electrical insulation and durability. Commonly used in automotive, industrial, and consumer electronics applications, the 19198-0047 simplifies assembly and reduces manufacturing costs by eliminating the need for soldering.
MOLEX 191980047 Avikrimp Spade Terminal Specifications:
- Overview: Solderless Terminals
- Description: Avikrimp Spade Tongue Terminal for 10-12 AWG Wire
- Product Family: Ring and Spade Terminals
- Series: 19198
- Type: Spade
- Wire Size AWG: 10, 12
- Wire Size mm²: 3.30-5.00
- Barrel Type: Closed
- Insulation: Nylon (PA)
- Material - Plating Mating: Tin
- Plating min - Mating: 2.540µm
- Plating min - Termination: 2.540µm
- Stud Size: 8 (M4)
- Wire Insulation Diameter: 5.70mm max.
- Flammability: 94V-0
- Net Weight: 2.286/g
- Packaging Type: Bag
- Engineering Number: C-841-08
- UPC: 800753046382
- Mil-Spec: N/A
- Crimp Quality Equipment: Yes
Buy the 19198-0047 MOLEX Avikrimp Spade Terminal | myMectronic
Secure your MOLEX 19198-0047 Avikrimp Spade Terminal with our trusted online platform.
Buy Now
Frequently Asked Questions
Where can I buy MOLEX 191980047?
You can click on the BUY or RFQ button to purchase 191980047 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 191980047?
You can download the 191980047 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 191980047?
MOLEX
