MOLEX 2002411215 Mega-Fit Power Connector
The MOLEX 200241-1215 Mega-Fit Power Connector is a robust right-angle header ideal for power distribution in wire-to-board applications. With a 5.70mm pitch and 5 circuits, it provides ample connectivity while maintaining space efficiency. The matte tin plating ensures excellent solderability and corrosion resistance, making it suitable for demanding industrial environments. Its right-angle design simplifies PCB layout and reduces stress on connections. The connector is designed to withstand a significant current load and offers reliable performance within a wide temperature range.
MOLEX 2002411215 Mega-Fit Power Connector Specifications:
- Product Family: Mega-Fit Power Connectors
- Application: Power, Wire-to-Board
- Current-Max: 23.5A
- Datasheet Order No: 987650-5401
- Pitch-Mating: 5.70mm
- Circuits (maximum): 5
- Durability (mating cycles max): 20
- Glow-Wire Capable: Yes
- Material - Resin: Liquid Crystal Polymer
- Material - Plating: Matte Tin
- Mating Material - Plating: Matte Tin
- Termination Material - Resin: Liquid Crystal Polymer
- Number of Rows: 1
- Orientation: Right Angle
- PCB Tail Length: 3.60mm
- PCB Retention: Yes
- Plating min - Mating: 1.524µm
- Plating min - Termination: 2.540µm
- Temperature Range - Operating: -40° to +105°C, -40° to +120°C
- Termination Interface: Style: Through Hole
- Voltage - Maximum: 600V AC (RMS)/DC
- Mates With: Mega-Fit Receptacle Housing 200456
Buy the 200241-1215 MOLEX Mega-Fit Power Connector | myMectronic
Purchase the MOLEX 200241-1215 Mega-Fit Power Connector securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy MOLEX 2002411215?
You can click on the BUY or RFQ button to purchase 2002411215 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 2002411215?
You can download the 2002411215 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 2002411215?
MOLEX
