MOLEX 2004850540 FFC FPC Connector
The Easy-On FFC/FPC connectors from the 200485 series feature a vertical, one-touch insertion design with auto lock-nail retention for quick, reliable connections. Designed for easy insertion, these connectors have a wide FFC/FPC mouth, making them suitable for consumer electronics, automotive, industrial automation, and data systems. They operate from -40°C to +105°C and include a visible release button for simple cable removal. Constructed with durable liquid crystal polymer housing, gold-plated copper contacts, and optional ground terminals, supporting up to 50V and 0.5A with at least 20 insertion cycles.
MOLEX 2004850540 FFC FPC Connector Specifications:
- Pitch - Mating Interface: 0.50mm
- Actuator Type: One-Touch
- Circuits (Loaded): 40
- Circuits (maximum): 40
- Color - Resin: Not specified
- Material - Metal: Copper Alloy
- Material - Plating Mating: Gold
- Material - Resin: Liquid Crystal Polymer
- Temperature Range - Operating: -40°C to +105°C
- Voltage - Maximum: 50V
- Current - Maximum: 0.5A
- Mated Height: 5.60mm
- PCB Mounting: Surface Mount
- Packaging Type: Embossed Tape on Reel
- Durability (mating cycles): 20
Buy the Molex Series Easy-On FFC FPC: 2004850540
Order the Molex FFC FPC connector online today for fast, secure assembly in consumer electronics, automotive systems, and industrial automation. Featuring a vertical design with a one-touch insertion and auto lock-nail, it ensures high retention force and reliable connections. The connector operates within a wide temperature range of -40°C to +105°C, supports voltages up to 50V and currents up to 0.5A, and is built with durable materials including gold-plated copper contacts and a liquid crystal polymer housing. Easy to use, with simple cable removal via a visible release button, it’s ideal for multiple industrial and electronic applications.
Get Molex 2004850540 today—built for quick, reliable FFC/FPC connections with easy one-touch operation.
Frequently Asked Questions
Where can I buy MOLEX 2004850540?
You can click on the BUY or RFQ button to purchase 2004850540 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 2004850540?
You can download the 2004850540 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 2004850540?
MOLEX
