MOLEX 2147502031 Micro-Fit 3.0 Cable Assembly
The MOLEX 214750-2031 is a Micro-Fit 3.0 female-to-female cable assembly designed for robust power and signal transmission in various applications. With a 150mm length and 3 circuits, this assembly offers flexibility and connectivity for wire-to-board and wire-to-wire connections. The gold plating on the mating interface and tin plating on the termination ensure reliable electrical contact, while the nylon resin provides insulation and durability. This assembly is ideal for applications requiring a secure and dependable connection within electronic systems.
MOLEX 2147502031 Micro-Fit 3.0 Cable Assembly Specifications:
- Product Family: Cable Assemblies
- Series: 214750
- Application: Power, Wire-to-Board, Wire-to-Wire
- Configuration: Dual Ended
- Connectors: Connector to Connector
- Overview: Micro-Fit Connector System
- Type: Discrete Wire Assembly
- UPC: 193264585083
- Cable Length: 150.00mm
- Circuits (Loaded): 3
- Color - Resin: Black
- Gender: Female-Female
- Lock to Mating Part: Yes
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Gold (Au)
- Material - Plating Termination: Tin
- Material - Resin: Nylon
- Net Weight: 6.782/g
- Number of Rows: 1
- Pitch - Mating Interface: 3.00mm
- Plating min - Mating: 0.762µm
- Plating min - Termination: 2.540µm
- Single Ended: No
- Wire Insulation Diameter: 1.85mm max.
- Wire Size AWG: 18
- Wire/Cable Type: Discrete Wire, UL 10002
- Current - Maximum per Contact: 8.5A
- EU ELV: Not Relevant
- EU RoHS: Compliant
- REACH SVHC: Not Contained
- Halogen-Free Status: Not Low-Halogen
- Mates With: Micro-Fit 3.0 Plug Housings, Micro-Fit TPA Plug Housing, Micro-Fit 3.0 Headers
- Reference - Drawing Numbers: Sales Drawing 2147502031-000
