MOLEX 2147512101 Micro-Fit 3.0 Cable Assembly
The MOLEX 214751-2101 is a Micro-Fit 3.0 female-to-pigtail cable assembly designed for power, wire-to-board, and wire-to-wire applications. This assembly provides a robust and reliable connection solution with a 150mm cable length, 10 circuits, and gold plating for the mating interface. Constructed with phosphor bronze and nylon materials, it is suitable for various industrial and commercial applications requiring secure and efficient power transmission.
MOLEX 2147512101 Micro-Fit 3.0 Cable Assembly Specifications:
- overview: Micro-Fit Connector System
- application: Power, Wire-to-Board, Wire-to-Wire Assembly
- configuration: Dual Ended
- connectors: Micro-Fit 3.0-to-Pigtail
- cable_length: 150.00mm
- circuits_loaded: 10
- color_resin: Black
- gender: Female-Pigtail
- lock_to_mating_part: Yes
- material_metal: Phosphor Bronze
- plating_mating: Gold (Au)
- plating_termination: Tin
- material_resin: Nylon
- net_weight: 20.149/g
- number_of_rows: 1
- pitch_mating_interface: 3.00mm
- plating_min_mating: 0.762µm
- plating_min_termination: 2.540µm
- single_ended: Yes
- wire_insulation_diameter_max: 1.85mm
- wire_size_awg: 18
- wire_cable_type: Discrete Wire, UL 10002
- current_maximum_per_contact: 8.5A
- elv: Not Relevant
- rohs: Compliant
- reach_svhc: Not Contained
- halogen_free_status: Not Low-Halogen
- mates_with_plug_housings: 43640, 200875
- mates_with_headers: 43650
- drawing_number: 2147512101-000
