MOLEX 2153232031 Mini-Fit Jr. Cable Assembly
The MOLEX 215323-2031 is a Mini-Fit Jr. male-to-pigtail off-the-shelf (OTS) cable assembly designed for power and wire-to-wire applications. It boasts a single-row configuration, a black resin body made of nylon, and brass terminals with gold mating plating and tin termination plating. This assembly is ideal for applications requiring a secure and reliable power connection, commonly found in industrial equipment, automotive systems, and consumer electronics.
MOLEX 2153232031 Mini-Fit Jr. Cable Assembly Specifications:
- overview: Mini-Fit Family Power Connectors
- application: Power, Wire-to-Wire Assembly
- configuration: Single Ended
- connector_type: Mini-Fit Jr.-to-Pigtail
- cable_length: 150.00mm
- circuits_loaded: 3
- color: Black
- gender: Male-Pigtail
- lock_to_mating_part: Yes
- material_metal: Brass
- material_plating_mating: Gold (Au)
- material_plating_termination: Tin
- material_resin: Nylon
- net_weight: 12.645/g
- number_of_rows: 1
- packaging_type: Bag
- pitch_mating_interface: 4.20mm
- plating_min_mating: 0.762µm
- plating_min_termination: 2.032µm
- wire_insulation_diameter: 1.80-3.10mm
- wire_size_awg: 16
- wire_cable_type: UL 1015
- current_maximum_per_contact: 9.0A
- voltage_maximum: 600V
- upc: 193264597727
- elv_compliance: Not Relevant
- rohs_compliance: Compliant
- reach_svhc_compliance: Not Contained
- halogen_free_status: Not Low-Halogen
- mates_with: Mini-Fit Jr. Receptacle Housing 5557, Mini-Fit TPA2 Cable Assembly 145135
- drawing_number: 2153232031-000
