MOLEX 2157602002 Micro-Fit+ Header
The MOLEX 215760-2002 is a Micro-Fit+ right-angle header within the 215760 series. This connector is designed for wire-to-board applications, offering a 3.00mm pitch and a compact profile. It features 2 circuits and a gold plating finish, ensuring reliable electrical performance and durability. The header is constructed with a high copper alloy for the metal components and liquid crystal polymer for the resin, providing excellent mechanical strength and heat resistance. It is RoHS compliant and suitable for a wide range of industrial and consumer electronics applications where a secure and space-saving connection is required.
MOLEX 2157602002 Micro-Fit+ Header Specifications:
- Pitch - Mating Interface: 3.00mm
- Pitch - Termination Interface: 3.00mm
- Plating min - Mating: 0.381µm
- Material - Resin: Liquid Crystal Polymer
- Material - Metal: High Copper Alloy
- Material - Plating: Gold
- Durability (mating cycles max): 200
- Current - Maximum per Contact: 12.5A
- Voltage - Maximum: 600V AC (RMS)/DC
- PCB Thickness - Recommended: 1.57mm
- PC Tail Length: 3.18mm
- Number of Rows: 1
- Orientation: Right Angle
- Net Weight: 0.408/g
- Temperature Range - Operating: -40° to +105°C
- Termination Interface: Style: Through Hole
- Circuits (maximum): 2
- Breakaway Circuits (Loaded): No
- Glow-Wire Capable: Yes
- Keying to Mating Part: Yes
- Lock to Mating Part: Yes
- Polarized to Mating Part: Yes
- Polarized to PCB: Yes
- Shrouded: Yes
