MOLEX 2177971081 KK 254 Cable Assembly
The MOLEX 217797-1081 is a KK 254-to-Pigtail Off-the-Shelf (OTS) cable assembly designed for applications needing pre-configured cable solutions. It features a dual-ended configuration with female-pigtail connectors, an 8-circuit design, and a 150mm cable length. Constructed with brass and nylon materials, and plated with tin, this assembly provides reliable and robust connectivity. It is RoHS compliant and suitable for various industrial and commercial applications.
MOLEX 2177971081 KK 254 Cable Assembly Specifications:
- overview: Off-the-Shelf Cable Assemblies
- assembly_configuration: Dual Ended
- connectors: KK 254-to-Pigtail
- cable_length: 150.00mm
- circuits_loaded: 8
- color_resin: Natural (White)
- material_metal: Brass
- material_plating_mating: Tin
- material_resin: Nylon
- net_weight: 6.794/g
- number_of_rows: 1
- pitch_mating_interface: 2.54mm
- plating_min_mating: 2.540µm
- single_ended: No
- termination_interface_style: Crimp or Compression
- wire_insulation_diameter_max: 1.57mm
- wire_size_awg: 22
- wire_cable_type: UL 11028
- upc: 195842123137
- material_plating_termination: Tin
- mates_with: KK254 PCB Headers 42375, 42377, 42376, 4030, 6373, 6410, 171856, 171857
- sales_drawing: 2177971081-000
Buy the 217797-1081 MOLEX KK 254 Cable Assembly | myMectronic
Purchase the MOLEX 217797-1081 cable assembly securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy MOLEX 2177971081?
You can click on the BUY or RFQ button to purchase 2177971081 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 2177971081?
You can download the 2177971081 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 2177971081?
MOLEX
