MOLEX 5055750571 Micro-Lock Plus Connector
The Micro-Lock PLUS Vertical Header is a 2.00mm pitch, single-row, wire-to-board connector designed for reliable electrical connections in industrial and electronic applications. It features matte tin plating for corrosion resistance, durable construction capable of withstanding up to 30 mating cycles, and operates within a temperature range of -40°C to +105°C. The black polyamide housing ensures durability, while the brass contacts provide excellent conductivity. This compact, stackable design is ideal for PCB automation, consumer electronics, and industrial automation systems where secure and repeatable connections are critical.
MOLEX 5055750571 Micro-Lock Plus Connector Specifications:
- Pitch: 2.00mm
- Number of Circuits: 5
- Color: Black
- Material - Metal: Brass
- Plating - Mating: Matte Tin
- Plating - Termination: Matte Tin
- Material - Resin: Polyamide
- Durability: 30 mating cycles
- Operating Temperature Range: -40°C to +105°C
- Current - Max per Contact: 3.0A
- Voltage - Max: 250V AC/DC
- Net Weight: 683.180 mg
- Orientation: Vertical
- PCB Retention: Yes
- Pad Pitch (mating and termination): 2.00mm
- Surface Mount: Yes
- RoHS, ELV, REACH: Compliant
- Packaging: Embossed Tape on Reel
- Application: Wire-to-Board Connection System
Buy the Molex 5055750571 – Reliable Micro-Lock Plus Wired Connection for Industrial Applications
Secure your electronic projects with the Micro-Lock Plus Connector. Featuring a 2.00mm pitch and 5 circuits, it ensures reliable, durable connections in industrial, automation, and consumer electronics. Its matte tin plating provides corrosion resistance, while the vertical, stackable design simplifies PCB assembly. Operating within -40°C to +105°C, it handles up to 3A at 250V, making it suitable for a wide range of applications. Trust this proven connector for dependable, repeated connections in your manufacturing and maintenance needs.
Buy Molex 5055750571 now and experience unmatched reliability and performance in your wire-to-board connections.
