MOLEX 2177971103 KK 254 Cable Assembly
The MOLEX 217797-1103 is a versatile Off-the-Shelf (OTS) cable assembly designed for connecting KK 254 connectors. This assembly offers a convenient solution for various applications requiring a pre-terminated cable with a 600mm length and 10 circuits. The assembly utilizes a 2.54mm pitch mating interface and features a natural (white) resin color. It is RoHS compliant and suitable for applications where a reliable and readily available cable connection is needed.
MOLEX 2177971103 KK 254 Cable Assembly Specifications:
- assembly_configuration: Dual Ended
- connectors: Connector to Connector
- pitch_mating_interface: 2.54mm
- circuits_loaded: 10
- cable_length: 600.00mm
- material_metal: Brass
- material_plating_mating: Tin
- material_plating_termination: Tin
- material_resin: Nylon
- net_weight: 26.945/g
- number_of_rows: 1
- plating_min_mating: 2.540µm
- wire_insulation_diameter_max: 1.57mm
- wire_size_awg: 22
- wire_cable_type: UL 11028
- gender: Female-Pigtail
- lock_to_mating_part: Yes
- single_ended: No
- termination_interface_style: Crimp or Compression
Buy the 217797-1103 MOLEX KK 254 Cable Assembly | myMectronic
Purchase the MOLEX 217797-1103 cable assembly securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy MOLEX 2177971103?
You can click on the BUY or RFQ button to purchase 2177971103 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 2177971103?
You can download the 2177971103 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 2177971103?
MOLEX
