MOLEX 2185091063 Milli-Grid Cable Assembly
The MOLEX 218509-1063 is a Milli-Grid-to-Milli-Grid Off-the-Shelf (OTS) cable assembly designed for reliable connections in diverse industrial settings. With a 2.00mm pitch, dual-row layout, and a 300mm length, this assembly provides flexibility and efficient signal transmission. Constructed with copper alloy and a polyester resin, it ensures durability and consistent performance. It is RoHS compliant and features a secure lock to mating parts, making it a dependable choice for various applications requiring robust cable connectivity.
MOLEX 2185091063 Milli-Grid Cable Assembly Specifications:
- overview: Milli-Grid Connector System
- description: Milli-Grid-to-Milli-Grid Off-the-Shelf (OTS) Cable Assembly
- pitch_mating_interface: 2.00mm
- length: 300.00mm
- circuits_loaded: 6
- color: Black (Resin)
- gender: Female-Female
- material_metal: Copper Alloy
- material_plating: Matte Tin
- material_resin: Polyester
- wire_size_awg: 24
- wire_cable_type: UL 10002
- current_maximum_per_contact: 2.0A
- voltage_maximum: 125V AC (RMS)/DC
- wire_insulation_diameter_max: 1.40mm
- number_of_rows: 2
- packaging_type: Bag
- net_weight: 4.807/g
- lock_to_mating_part: Yes
Buy the 218509-1063 MOLEX Milli-Grid Cable Assembly | myMectronic
Purchase the MOLEX 218509-1063 Milli-Grid Cable Assembly securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy MOLEX 2185091063?
You can click on the BUY or RFQ button to purchase 2185091063 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 2185091063?
You can download the 2185091063 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 2185091063?
MOLEX
