MOLEX 22162080 PCB Connector
The KK 254 PC Board Connector is a reliable right-angle, end-to-end stackable connector designed for PCB applications. With 8 gold-plated circuits, it features a 3.35mm pitch and is made from flame-retardant nylon with a brass base and gold plating for durability and excellent electrical conductivity. Suitable for board-to-board connections, it supports up to 2.5A per contact and a maximum voltage of 500V. This high-quality connector is RoHS compliant, halogen-free, and suitable for industrial and electronic equipment requiring reliable PCB interfacing.
MOLEX 22162080 PCB Connector Specifications:
- Number of Circuits: 8
- Color - Resin: Natural (White)
- Flammability: 94V-0
- Plastic Material: Nylon
- Metal Material: Brass
- Plating - Mating: Gold
- Plating - Termination: Tin
- Maximum Current per Contact: 2.5A
- Maximum Voltage: 500V
- Pitch - Mating Interface: 2.54mm
- Pitch - Termination Interface: 2.54mm
- Operating Temperature Range: -55°C to +105°C
- PC Tail Length: 3.35mm
- Orientation: Right Angle
- PCB Thickness - Recommended: 1.60mm
- Seam: Through Hole
- Lock to Mating Part: None
- Guide to Mating Part: None
- Net Weight: 0.842g
Buy the Molex 22162080 – Reliable PCB Connector for Industrial Applications
Secure your electronic assemblies with the reliable PCB connector designed for industry applications. Featuring 8 gold-plated circuits, a 3.35mm pitch, and a durable nylon housing, this connector ensures optimal electrical conductivity and mechanical stability. It is suitable for stackable board-to-board mounting, supporting up to 2.5A per contact and operating at voltages up to 500V. RoHS compliant and halogen-free, it’s ideal for high-demand environments requiring robust and safe connection solutions. Purchase online for quick delivery and trusted quality.
Get Molex 22162080 today—built for precision and long-lasting durability in PCB connections with high electrical performance.
Frequently Asked Questions
Where can I buy MOLEX 22162080?
You can click on the BUY or RFQ button to purchase 22162080 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 22162080?
You can download the 22162080 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 22162080?
MOLEX
