MOLEX 526100633 FFC FPC Connector
The Easy-On FFC/FPC Connector with 1.00mm pitch features a vertical slider series, height of 5.75mm, and accommodates 6 circuits. Constructed with phosphor bronze contact material and tin-silver-bismuth plating, it offers easy SMT installation with an embossed tape packaging type. Rated for operating temperatures from -40°C to +85°C, it supports a maximum current of 1.0A and voltage of 125V. Certifications include UL and CSA, ensuring reliable performance for industrial and electronic applications. Ideal for flexible flat cables in compact electronic devices.
MOLEX 526100633 FFC FPC Connector Specifications:
- Pitch - Mating Interface: 1.00mm
- Number of Circuits: 6
- Height: 5.75mm
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Tin-Silver-Bismuth
- Material - Plating Termination: Tin-Silver-Bismuth
- Flammability: 94V-0
- Temperature Range - Operating: -40°C to +85°C
- Current - Maximum per Contact: 1.0A
- Voltage - Maximum: 125V
- Packaging Type: Embossed Tape on Reel
- Actuator Type: Slider
- Orientation: Vertical
- Mated Height: 5.75mm
- Color - Resin: Natural
- Wire/Cable Type: FFC/FPC
- PCB Mounting: Surface Mount
- Durability: 30 mating cycles
Buy the Molex 52610U2013 Reliable Flexible Flat Cable Connectors for Industrial Applications
Secure your flexible flat cable connections with the Molex Series52610 FFC-FPC connector, offering 6 circuits, a 1.00mm pitch, and UL/CSA certifications. Designed for easy SMT installation, this connector features a vertical slider, operating over a temperature range of -40°C to +85°C. Its durable phosphor bronze contact material with tin-silver-bismuth plating ensures reliable electrical performance and long-term durability. Ideal for smartphones, tablets, and compact electronic devices, this connector provides a high-quality, easy-to-use solution for modern electronics assembly.
Order your Molex Series52610 FFC-FPC connector today and enhance your electronic device assembly with dependable, high-quality flexible cable connections.
