MOLEX 26481081 vertical header connector
The KK 396 Breakaway Header from Molex is a vertical, 8-circuit connector designed for reliable board-to-board and wire-to-board connections. Featuring tin (Sn) plating and a durable polypropylene resin, it supports up to 25 mating cycles with a polarization and keying mechanism for secure mating. It operates within a temperature range of -55°C to +105°C, has a pitch of 3.96mm, and a net weight of 2.273 grams. Certified by CSA and UL, it is ideal for industrial, automation, and electronic hardware applications requiring secure, reusable connection interfaces.
MOLEX 26481081 vertical header connector Specifications:
- Circuits: 8
- Color - Resin: Black
- Flammability: 94V-0
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- Net Weight: 2.273 grams
- Orientation: Vertical
- PCB Tail Length: 1.60mm
- Pin Pitch - Mating Interface: 3.96mm
- Voltage Maximum: 250V
- Current Maximum: 7.0A
- Temperature Range - Operating: -55°C to +105°C
- Durability - Mating Cycles Max: 25
- Certifications: CSA, UL
- Process Temperature Max: 235°C
- Packaging: Bag
- Approvals: RoHS Compliant, China RoHS, REACH SVHC Not Contained
Buy the Molex 0026481081 – Reliable KK Interconnect System for Industrial Applications
Order the Molex KK 396 vertical header connector today to ensure secure, reusable, and reliable connections for industrial, automation, or electronic projects. Featuring durable tin plating, polarization, and easy mounting, this 8-circuit connector operates within a wide temperature range of -55°C to +105°C. Its compact design with a 3.96mm pitch makes it suitable for various PCB and wire-to-board applications. Trust Molex’s quality standards with CSA and UL certifications. Secure your electronic assemblies with this high-performance connector—buy online now and enhance your project's reliability.
Buy Molex 0026481081 now and experience unmatched reliability and performance in your electronic connection systems.
Frequently Asked Questions
Where can I buy MOLEX 26481081?
You can click on the BUY or RFQ button to purchase 26481081 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 26481081?
You can download the 26481081 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 26481081?
MOLEX
