MOLEX 26602040 PCB Header
The KK 396 Header is a vertical, tin-plated, 4-circuit connector designed for reliable board-to-board and wire-to-board applications. It features robust brass contacts with a 3.96mm pitch, accommodating up to 4 circuits with a maximum of 4 loaded circuits. The header is UL and CSA certified, RoHS compliant, and rated for operating temperatures up to 105°C. Its durable design includes a net weight of 1.092 grams and supports 25 mating cycles, making it suitable for industrial automation, electronic control systems, and power distribution modules.
MOLEX 26602040 PCB Header Specifications:
- Number of Circuits: 4
- Circuits (Maximum): 4
- Color - Resin: Natural
- Durability - Mating Cycles Max: 25
- Flammability: 94V-0
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- Net Weight: 1.092 grams
- Orientation: Vertical
- PC Tail Length: 3.56mm
- PCB Thickness - Recommended: 1.60mm
- Pitch - Mating Interface: 3.96mm
- Maximum Voltage: 250V
- Maximum Current - Per Contact: 7.0A
- Operating Temperature Range: -55°C to +105°C
- Temperature Max Process: 235°C
- Lead-Free Process Capability: Yes
- UL & CSA Certified
- RoHS & China RoHS Compliant
Buy the Molex 26602040 – Reliable PCB Header for Industrial Applications
Secure your electronic assembly with the Molex PCB Header, featuring a 3.96mm pitch, tin-plated brass contacts, and UL/CSA certification. Engineered for high durability, it supports up to 25 mating cycles and operates efficiently within a temperature range of -55°C to +105°C. Perfect for industrial automation, power distribution, and control systems, this reliable connector ensures secure connections and long-lasting performance in demanding environments. Order online today and enhance your project with proven quality and precision.
Buy Molex 26602040 now and benefit from a durable, UL and CSA certified connector ideal for power, automation, and control systems.
Frequently Asked Questions
Where can I buy MOLEX 26602040?
You can click on the BUY or RFQ button to purchase 26602040 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 26602040?
You can download the 26602040 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 26602040?
MOLEX
