MOLEX 26481086 PCB Power Header
The KK 396 Breakaway Header from Molex is a right-angle PCB connector featuring 8 circuits, tin-plated brass contacts, and a friction lock for secure mating. Designed for power and wire-to-board applications, it offers durable performance with up to 25 mating cycles and operates within a temperature range of -40°C to +105°C. The black polyester housing ensures reliable insulation, while the 3.96mm pitch suits various electronic assembly needs. RoHS compliant and UL/CSA certified, this connector is ideal for rugged industrial environments requiring high reliability and secure connections.
MOLEX 26481086 PCB Power Header Specifications:
- Number of Circuits: 8
- Color - Resin: Black
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Resin: Polyester
- Net Weight: 3.368 grams
- Orientation: Right Angle
- Pitch - Mating Interface: 3.96mm
- Pitch - Termination Interface: 3.96mm
- Temperature Range - Operating: -40°C to +105°C
- Current - Maximum per Contact: 7.0A
- Voltage - Maximum: 250V
- Durability (Mating Cycles Max): 25
- Flammability: 94V-0
- Seam: Friction Lock
- Contact Termination: Through Hole
- Packaging Type: Bag
- UL and CSA Certified, RoHS and Reach Compliant
Buy the Molex 0026481086 – Reliable Right-Angle Power Connector for Industrial Applications
Order the Molex PCB Power Header now for secure, reliable connections in industrial electronics. Featuring 8 circuits, a friction lock, and tin-plated brass contacts, it ensures high durability with up to 25 mating cycles. Designed for power applications, it operates within -40°C to +105°C and is RoHS, UL, and CSA compliant for peace of mind. Its compact right-angle design with a 3.96mm pitch makes it ideal for space-constrained electronic assemblies. Purchase online to get fast delivery and expert support.
Buy Molex 0026481086 now and experience unmatched reliability and performance in industrial power and wire-to-board connections.
Frequently Asked Questions
Where can I buy MOLEX 26481086?
You can click on the BUY or RFQ button to purchase 26481086 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 26481086?
You can download the 26481086 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 26481086?
MOLEX
