MOLEX 26481091 board-to-board connector
The KK 396 Breakaway Header from Molex is a vertical, 9-circuit connector designed for reliable board-to-board and wire-to-board applications. Featuring tin (Sn) plating on brass contacts, it offers durability with up to 94 mating cycles, operates within a temperature range of -55°C to +105°C, and complies with RoHS and UL standards. The header provides a 3.96mm pitch, is shrouded, and is suitable for PCB thicknesses of 1.60mm. Its black resin housing facilitates easy assembly and secure connections in electronic and industrial systems.
MOLEX 26481091 board-to-board connector Specifications:
- Circuits: 9
- Color - Resin: Black
- Flammability: 94V-0
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- Net Weight: 2.837 grams
- Orientation: Vertical
- PCB Tail Length: 1.60mm
- Pitch - Mating Interface: 3.96mm
- Voltage - Maximum: 250V
- Current - Maximum: 7.0A per contact
- Temperature Range - Operating: -55°C to +105°C
- Durability (mating cycles max): 94
- Shrouded: Yes
- Stackable: No
Buy the Buy Molex KK 396 Part Number 0026481091 Online
Enhance your electronic assemblies with the Molex KK 396 Breakaway Header, a versatile 9-circuit vertical connector with durable tin plating. Designed for PCB and wire-to-board systems, it offers excellent mateability with up to 94 mating cycles, operating seamlessly within a wide temperature range. The shrouded, black resin housing provides secure, interference-free connections. With a 3.96mm pitch, this high-quality connector ensures reliable performance in industrial, consumer electronics, and automation applications, making it the ideal choice for professional-grade projects.
Order your Molex Series 41661 KK 396 connector today and ensure reliable, high-quality connections for your electronic projects.
Frequently Asked Questions
Where can I buy MOLEX 26481091?
You can click on the BUY or RFQ button to purchase 26481091 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 26481091?
You can download the 26481091 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 26481091?
MOLEX
