MOLEX 26481115 Wire-to-Board Header
The Molex KK 396 Breakaway Header is a vertical, square pin connector with friction lock, designed for reliable wire-to-board connections in electronic applications. Featuring 11 circuits and tin (Sn) plating, it offers durability with up to 20 mating cycles, operating efficiently within a temperature range of -55°C to +105°C. Made from durable polyester and metal, it ensures secure connections with a 3.96mm pitch and a maximum current of 7.0A at 250V. Suitable for manufactured electronic systems requiring robust, dependable headers.
MOLEX 26481115 Wire-to-Board Header Specifications:
- Type: KK interconnect system - Molex
- Configuration: Vertical, square pin, friction lock
- Number of Circuits: 11
- Maximum Circuits: 20
- Color: Resin - None specified
- Durability: Up to 20 mating cycles
- Material - Metal: Metal with tin (Sn) plating
- Material - Resin: Polyester
- Net Weight: 3.709 grams
- Position: Fixed orientation
- Pitch - Mating Interface: 3.96mm
- Pitch - Termination Interface: 3.96mm
- Operating Temperature Range: -55°C to +105°C
- Current per contact: 7.0A
- Voltage maximum: 250V
- PCB Tail Length: 1.60mm
- Solder Process: Not specified, suitable for wave soldering
- Flammability: UL 94V-0
- Standards & Certifications: CSA, UL, RoHS compliant
- Packaging: Bag
Buy the Molex 26481115 – Reliable Connectors for Industrial Applications
Secure your electronic assemblies with the Molex wire-to-board header. Designed for durability and reliability, it features 11 circuits, tin plating, and a 3.96mm pitch. Ideal for industrial applications requiring a robust connection system, it supports up to 7.0A per contact and features UL and CSA certification. The vertical configuration ensures easy mounting, while its high temperature tolerance of -55°C to +105°C guarantees performance in demanding environments. Purchase online now for quality and dependable connections.
Get Molex 26481115 today—built for precision and long-lasting durability in electronic and industrial connections.
Frequently Asked Questions
Where can I buy MOLEX 26481115?
You can click on the BUY or RFQ button to purchase 26481115 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 26481115?
You can download the 26481115 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 26481115?
MOLEX
