MOLEX 26604110 Vertical Header Connector
The KK 396 Header is a robust, vertical, friction-lock connector featuring 11 circuits with tin-plated brass contacts, designed for wire-to-board power and signal applications. It supports up to 94V-0 flammability rating, 7A current capacity, and maximum voltage of 250V. Constructed with durable polyester resin, it offers reliable mating with a 3.96mm pitch and PC tail length of 3.56mm. This high-quality connector ensures secure, polarization-friendly connections suitable for automation, industrial control, and electronic device integration in diverse environments.
MOLEX 26604110 Vertical Header Connector Specifications:
- Number of Circuits: 11
- Color - Resin: Natural
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Flammability: 94V-0
- Durability (mating cycles max): 25
- Maximum Current per Contact: 7.0A
- Maximum Voltage: 250V
- Temperature Range - Operating: -25°C to +85°C
- Pitch - Mating Interface: 3.96mm
- PCB Tail Length: 3.56mm
- Net Weight: 4.114 grams
- Stackable: No
- Lock to Mating Part: Friction Lock
- Shrouded: No
- Termination Interface Style: Through Hole
- PCB Thickness - Recommended: 1.60mm
- Packaged in Bag
- UL and CSA Certified
Buy the Molex Series KK: KK 396 Header: 26604110
Enhance your electronic assembly with the Molex KK 396 Header, a high-quality, reliable connector designed for power and signal connections on PCBs. Featuring 11 circuits, a 3.96mm pitch, and a rugged construction with tin-plated contacts, it offers superior performance in industrial automation, control systems, and electronic devices. Its friction lock ensures secure mating, while its RoHS compliance guarantees environmentally friendly manufacturing. Purchase online today and experience durable, high-performance connectivity tailored for your demanding applications.
Get Molex KK 396 Header today—built for precision and long-lasting durability in industrial and electronic wiring applications.
