MOLEX 26605080 KK 396 Header
The MOLEX 26-60-5080 KK 396 header is a versatile and reliable solution for wire-to-board connectivity. Designed with 8 circuits and a right-angle orientation, this header is suitable for a wide range of applications, including power distribution and signal transmission. The tin plating ensures excellent solderability and corrosion resistance, while the robust construction provides long-lasting performance. Compatible with various MOLEX housings and connectors, the 26-60-5080 simplifies assembly and ensures a secure, professional connection.
MOLEX 26605080 KK 396 Header Specifications:
- overview: KK Interconnect System
- application: Power, Wire-to-Board
- circuits_loaded: 8
- circuits_maximum: 8
- color_resin: Natural
- durability_mating_cycles: 25
- flammability: 94V-0
- glow_wire_capable: No
- lock_to_mating_part: Yes
- material_metal: Brass
- material_plating_mating: Tin (Sn)
- material_plating_termination: Tin
- material_resin: Polyester
- number_of_rows: 1
- orientation: Right Angle
- pc_tail_length: 3.96mm
- pcb_locator: No
- pcb_retention: None
- pcb_thickness_recommended: 1.60mm
- packaging_type: Bag
- pitch_mating_interface: 3.96mm
- plating_min_mating: 5.080µm
- plating_min_termination: 5.080µm
- polarized_to_mating_part: Yes
- polarized_to_pcb: No
- shrouded: Partial
- stackable: Yes
- temperature_range_operating: See Product Specification
- termination_interface_style: Through Hole
- current_max_per_contact: 7.0A
- voltage_max: 250V
- duration_at_max_process_temperature_seconds: 005
- lead_free_process_capability_wave_max_cycles: 001
- process_temperature_max_celsius: 235
- engineering_number: 41792-0008
- drawing_numbers: PS-08-50-001, SDA-41792-000, SDA-41792-002
