MOLEX 350230007 Board-in Housing
The MOLEX 35023-0007 is a right-angle board-in connector housing designed for secure and reliable connections in a variety of electronic applications. This housing, part of the 35023 series, features a 2.00mm pitch and is specifically designed to accommodate 7 circuits. Constructed from durable nylon, it offers excellent insulation and mechanical strength. The connector is RoHS compliant and suitable for signal transmission. It is commonly used in applications requiring a right-angle connection to printed circuit boards, providing flexibility in design and layout. Refer to the associated product specification and sales drawing for detailed dimensions and usage guidelines.
MOLEX 350230007 Board-in Housing Specifications:
- status: Active
- description: 2.00mm Pitch Board-in Housing, Right-Angle, 7 Circuits, Natural
- product_family: Crimp Housings
- application: Signal
- upc: 800753876668
- circuits_maximum: 7
- color_resin: Natural
- flammability: 94V-0
- gender: Receptacle
- glow_wire_capable: No
- material_resin: Nylon
- net_weight_g: 0.146
- number_of_rows: 1
- packaging_type: Bag
- panel_mount: No
- pitch_mating_interface: 2.00mm
- stackable: No
- temperature_range_operating_c: -40 to +105
- lead_free_process_capability: N/A
- eu_elv: Not Relevant
- eu_rohs: Compliant
- china_rohs: Compliant
- reach_svhc: Not Contained
- halogen_free_status: Low-Halogen
- rohs_phalates: Not Contained
- use_with_straight_terminal: 350449102, 350449260
- use_with_right_angle_terminal: 350211201, 350211301, 350211360
