MOLEX 353630450 Wire-to-Board Connector
The Sherlock Wire-to-Board Connector System features a 2.00mm pitch, right-angle header with positive lock, 4 circuits, and a white, glass-filled resin housing. Designed for reliable electrical connections, it supports up to 2.0A per contact and operates within a temperature range of -40°C to +105°C. This connector is UL and CSA certified, halogen-free, RoHS compliant, and designed for up to 30 mating cycles while ensuring durability and secure connections in various medical, industrial, and consumer applications. It mates with Sherlock housing, providing a compact and robust solution.
MOLEX 353630450 Wire-to-Board Connector Specifications:
- Pitch: 2.00mm
- Number of Circuits: 4
- Material - Resin: Nylon
- Color - Resin: Natural
- Maximum Current per Contact: 2.0A
- Maximum Voltage: 125V
- Operating Temperature Range: -40°C to +105°C
- Flammability Rating: UL 94V-0
- Mating Cycles: Up to 30
- Locking Mechanism: Positive lock
- Orientation: Right angle
- Tail Length: 1.60mm
- PC Tail Length: 3.20mm
- Termination Style: Through hole
- Surface Mount Compatible: No
- Shrouded: No
- Stackable: No
- RoHS Compliance: Yes
Buy the Buy Molex Sherlock Wire-to-Board Part Number 353630450 Online
Experience the precision and durability of the Molex Sherlock Wire-to-Board Connector system. With a 2.00mm pitch, 4 circuits, and a secure positive lock, it ensures reliable electrical connections suitable for industrial, medical, and consumer electronics. Its robust nylon housing withstands temperatures from -40°C to +105°C, supporting up to 30 mating cycles. UL and CSA certified, halogen-free, and RoHS compliant, this connector offers a compact, stackable, and shrouded-free design for versatile applications, available for quick online purchase.
Get Molex Sherlock 353630450 today—designed for secure, high-reliability connections in compact electronic assemblies.
Frequently Asked Questions
Where can I buy MOLEX 353630450?
You can click on the BUY or RFQ button to purchase 353630450 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 353630450?
You can download the 353630450 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 353630450?
MOLEX
