MOLEX 387206305 Barrier Strip
The Beau Barrier Strip is a 9.53mm pitch PCB terminal strip with five circuits, ideal for secure electrical connections. Constructed from durable brass with tin plating on metal parts and polyester resin housing, it features a horizontal entry angle and is suitable for operating temperatures from -40°C to +130°C. Designed for easy installation without mounting ends, it supports wire sizes from AWG 14 to 22 and a maximum current of 15A per contact at up to 300V. Compact and reliable for various industrial and electronic applications.
MOLEX 387206305 Barrier Strip Specifications:
- Circuits (Loaded): 5
- Color - Resin: Black
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- Entry Angle: Horizontal
- PCB Thickness - Recommended: 3.18mm
- Pitch - Mating Interface: 9.53mm
- Voltage - Maximum: 300V
- Current - Maximum per Contact: 15.0A
- Temperature Range - Operating: -40°C to +130°C
- Wire Size mm: 0.50-1.50
- Wire Size AWG: 14, 16, 18, 20, 22
Buy the Molex Series 38720 Barrier Strip: 0387206305
Experience reliable electrical connections with the Molex Barrier Strip, featuring a 9.53mm pitch and five circuits. Constructed from durable brass and polyester, it operates in temperatures from -40°C to +130°C. Supports multiple wire sizes from AWG 14 to 22, with a maximum current of 15A per contact at up to 300V. Ideal for industrial and electronic applications, this PCB terminal strip offers easy installation, high durability, and secure interfacing for various electrical systems. Buy online now for dependable, long-lasting performance.
Get Molex 0387206305 today—designed for secure, high-current PCB connections with robust construction and versatile wire compatibility.
Frequently Asked Questions
Where can I buy MOLEX 387206305?
You can click on the BUY or RFQ button to purchase 387206305 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 387206305?
You can download the 387206305 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 387206305?
MOLEX
