MOLEX 391001903 Eurostyle Barrier Strip
Eurostyle Two-Screw Barrier Strips are low-profile, 8.00mm pitch terminal connectors designed for wire-to-wire applications. They feature three circuits, with a stainless steel metal part and nylon low-halogen resin body, ensuring durability and safety. These barrier strips operate within a temperature range of -40°C to +105°C and are designed with vertical orientation and PCB retention for secure mounting. Suitable for various electrical wiring setups, their robust construction ensures reliable connection and easy installation in industrial and electronic control systems. RoHS compliant and halogen-free, they meet environmental standards.
MOLEX 391001903 Eurostyle Barrier Strip Specifications:
- Pitch - Mating Interface: 8.00mm
- Pitch - Termination Interface: 8.00mm
- Number of Circuits: 3
- Material - Metal: Stainless Steel
- Material - Resin: Nylon Low-Halogen
- Operating Temperature Range: -40°C to +105°C
- Hardware: Two-Screw Barrier Strips, Vertical Orientation
- PCB Retention: Yes
- Color: White Resin
- Mounting Holes: Between Circuits
- RoHS Compliance: Yes
- Halogen-Free: Yes
- Voltage Rating: 300V
- Current per Contact: 20.0A
- Application: Wire-to-Wire
- Mounting: Panel Mount
- Contact Finish: Not specified
Buy the Molex Series 39100 Eurostyle Barrier Strip: 0391001903
Purchase Molex Eurostyle Barrier Strips online today and ensure secure, reliable wire-to-wire connections for your electronic or industrial projects. With a robust design featuring stainless steel contacts and nylon low-halogen resin, these barrier strips provide excellent durability and safety. The 8.00mm pitch and three circuit setup make installation straightforward in various control systems. RoHS compliant, halogen-free, and operating within -40°C to +105°C, this product offers optimal performance and environmental safety. Order now and experience hassle-free wiring solutions that meet modern standards.
Buy Molex Eurostyle Two Screw barrier strips now and enjoy reliable wire-to-wire connections for industrial and electronic applications.
