MOLEX 391001906 Eurostyle Barrier Strip
Eurostyle Two-Screw Barrier Strips are low-profile, 8.00mm pitch connector blocks designed for wire-to-wire applications. These terminals feature six circuits with stainless steel metal components and nylon low-halogen resin housing, ensuring durability and safety. They support wire sizes from AWG 12 to 22, with a maximum current of 20A per contact and voltage of 300V. Suitable for vertical orientation, they also include mounting holes for PCB or panel installation, offering reliable electrical connections in industrial automation and control systems within a temperature range of -40°C to +105°C.
MOLEX 391001906 Eurostyle Barrier Strip Specifications:
- Pitch: 8.00mm
- Number of Circuits: 6
- Material - Metal: Stainless Steel
- Material - Resin: Nylon Low-Halogen
- Wire Size: AWG 12-22
- Current - Maximum per Contact: 20A
- Voltage - Maximum: 300V
- Operating Temperature Range: -40°C to +105°C
- Mounting: PCB and Panel Mounting Holes
- Contact Type: Barrier Strip with Two-Screw Connection
- Color: White
- RoHS and China RoHS Compliant
- Application: Wire-to-Wire Connections
- Orientation: Vertical
- Entry Angle: Horizontal
Buy the Buy Molex Eurostyle Two-Screw Part Number 391001906 Online
Purchase Molex Eurostyle Barrier Strip with 6 circuits, 8mm pitch, and stainless steel construction for secure wire-to-wire connections. Ideal for industrial automation, control panels, and wiring systems, it supports wire sizes from AWG 12 to 22, delivering up to 20A current and 300V voltage. Its durable nylon housing and mounting options make installation easy and secure. Ensure your electrical projects perform reliably in a temperature range of -40°C to +105°C; buy online today for quick, dependable delivery.
Buy Molex Eurostyle Two-Screw Part Number 391001906 now and experience reliable, durable wiring solutions with high current capacity and voltage stability.
