MOLEX 39301181 Power Connector
Mini-Fit Jr. power connector with 18 circuits designed for reliable wire-to-board application. Features dual-row, right-angle design with snap-in plastic PCB lock, 0.76um gold plating, and PA Polyamide Nylon 6/6 material. Rated for 13A per circuit, operating within -40°C to +105°C, with robust UL and CSA certification for safety. Compact pitch of 4.20mm ensures efficient space utilization. Suitable for high-current, low-profile electrical assemblies in industrial and electronic systems, providing durability and easy mating with compatible connectors.
MOLEX 39301181 Power Connector Specifications:
- Number of Circuits: 18
- Current per Circuit: 13A
- Voltage Rating: 600V
- Operating Temperature Range: -40°C to +105°C
- Material: PA Polyamide Nylon 6/6
- Color - Resin: Matte Tin
- Plating - Mating Interface: 0.762um Gold
- Plating - Termination: 2.540um Gold
- Pitch - Mating Interface: 4.20mm
- Orientation: Right Angle
- Locking Mechanism: Snap-in Plastic Lock
- PCB Thickness - Recommended: 1.78mm
- Termination Interface: Through Hole
- Shrouded: Fully
- Stackable: No
- Surface Mount Compatible: No
- Temperature Range - Operating: -40° to +105°C
- Certifications: UL Listed, CSA Certified
- RoHS Compliant, Low Halogen
- Durability (mating cycles max): Not specified
- Material - Metal: Nickel Plated Brass
- Guide to Mating Part: 5557 Mini-Fit Jr. Receptacle Housing
Buy the Molex Series Mini-Fit Jr Power Connector: 39301181
Enhance your electrical assemblies with this 18-circuit Mini-Fit Jr. power connector featuring dual-row, right-angle design, 13A per circuit capacity, and gold-plated contacts. Crafted from durable PA Polyamide Nylon 6/6, it offers excellent thermal stability from -40°C to +105°C and is compliant with RoHS standards. Its compact 4.20mm pitch, snap-in lock, and fully shrouded design ensure secure, reliable connections for industrial, electronic, and automation systems. Purchase online now for dependable performance and easy integration into your projects.
Get Molex 39301181 today—built for high-current applications with durable nylon construction and reliable locking for long-lasting connections.
Frequently Asked Questions
Where can I buy MOLEX 39301181?
You can click on the BUY or RFQ button to purchase 39301181 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 39301181?
You can download the 39301181 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 39301181?
MOLEX
