MOLEX 430450620 Micro-Fit Power Connector
The Micro-Fit 3.0 Vertical Header is a compact, robust connector designed for PCB applications. Featuring a 3.00mm pitch with dual rows and 6 circuits, it offers high durability with a maximum of 30 mating cycles and is made from high-temperature thermoplastic with gold-plated brass contacts. Its shrouded, polarized design ensures reliable connections in power and wire-to-board systems, suitable for household and industrial electronics. Certified by UL and CSA, it supports operating temperatures from -40°C to +105°C and can handle currents up to 8.5A at 600V, making it ideal for high-performance power applications.
MOLEX 430450620 Micro-Fit Power Connector Specifications:
- Circuits (Loaded): 6
- Circuits (Maximum): 6
- Color - Resin: Black
- Durability (Mating Cycles Max): 30
- Flammability: 94V-0
- Glow-Wire Capable: Yes
- Mated Height: 17.64mm
- Material - Metal: Brass
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Material - Resin: High Temperature Thermoplastic
- Surface Mount Compatible (SMC): Yes
- Temperature Range - Operating: -40°C to +105°C
- Current - Maximum per Contact: 8.5A
- Voltage - Maximum: 600V
- Pitch - Mating Interface: 3.00mm
- Packaging Type: Embossed Tape on Reel
- Lead-free Process Capability: Reflow at 260°C for 30 seconds
- Max. Cycles at Max. Process Temperature: 260°C
Buy the Buy Molex Micro-Fit 3.0 Part Number 0430450620 Online
Purchase the Molex Micro-Fit 3.0 vertical connector part number 0430450620 online today. Designed for power applications, it features a 3.00mm pitch with dual rows, gold-plated contacts, and a robust thermoplastic body. Suitable for PCB wiring, it supports operating temperatures from -40°C to +105°C, handles up to 8.5A at 600V, and is UL/CSA certified. Its shrouded, polarized design ensures reliable connection in industrial and household electronics, delivering long-lasting durability and easy integration into your projects.
Get Molex Micro-Fit 3.0 0430450620 today—built for high-current power connections and durable performance in electronics assembly.
Frequently Asked Questions
Where can I buy MOLEX 430450620?
You can click on the BUY or RFQ button to purchase 430450620 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 430450620?
You can download the 430450620 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 430450620?
MOLEX
