MOLEX 460150402 Power Connector
The Mini-Fit Plus Header is a dual-row, vertical PCB connector with four circuits, designed for reliable wire-to-board connections in industrial applications. Made of durable PA Polyamide Nylon 6/6 with UL 94V-0 flammability rating, it features tin (Sn) over nickel (Ni) plating on copper alloy contacts, ensuring excellent electrical and mechanical performance. The connector supports up to 13A per circuit at 600V, has a 4.20mm pitch, and is polarized for mating with shrouded, fully stackable, non-surface mount design. Suitable for operating temperatures from -40°C to +105°C, it's ideal for power and control systems requiring high current capacity and safety compliance.
MOLEX 460150402 Power Connector Specifications:
- Number of Circuits: 4
- Current per Circuit: 13A
- Voltage Rating: 600V
- Material - Contact: Copper Alloy
- Plating - Contact: Tin over Nickel
- Housing Material: PA Polyamide Nylon 6/6
- Flammability Rating: UL 94V-0
- Operating Temperature: -40°C to +105°C
- Pitch: 4.20mm
- PCB Tail Length: 1.80mm
- Contact Resistance: Not specified
- Durability: Up to 25 mating cycles
- Mounting Style: Through Hole
- Polarized: Yes
- Shrouded: Fully
- Maximum Mating Cycles: Not specified
- Rated Voltage: 600V
- Maximum Current: 13A per circuit
- Net Weight: Approximate 1.315g
- Certifications: UL, CSA
- RoHS Compliant: Yes
Buy the Molex 4600150402 – Reliable Power Connector for Industrial Applications
Enhance your power distribution systems with the Molex Mini-Fit Plus Power Connector, supporting up to 13A at 600V. This dual-row, vertical PCB header is made of durable nylon with tin over nickel plating on copper contacts, ensuring reliable electrical performance. Its polarized, fully shrouded, through-hole design facilitates easy assembly and secure connections. Operating from -40°C to +105°C, it meets UL and CSA standards, making it ideal for industrial power, automation, and control systems requiring high current capacity and safety compliance. Order online today for fast delivery and quality assurance.
Order your Molex Series 4600150402 power connector today and give your industrial projects the dependable quality they deserve with high current capacity and robust design.
