MOLEX 430450814 Power Connector
The Micro-Fit 3.0™ Vertical Header is a high-reliability, 3.00mm pitch, dual-row power connector designed for wire-to-board applications. Crafted from high-temperature, halogen-free thermoplastic and plated with gold for optimal conductivity, it features 8 circuits with a maximum current of 5.0A per contact and a voltage capacity of 600V. The connector supports up to 30 mating cycles, has a mated height of 17.64mm, and is suitable for operating temperatures from -40°C to +105°C. It is CSA and UL certified, RoHS compliant, and compatible with SMC processes and wave soldering. Its compact, shrouded, stackable design ensures secure PCB mounting and reliable electrical connections, making it ideal for power supplies, industrial instrumentation, and electronic systems requiring durable wire-to-board interconnects.
MOLEX 430450814 Power Connector Specifications:
- Pitch: 3.00mm
- Number of Circuits: 8
- Current: 5.0A per contact
- Voltage: 600V
- Maximum Mating Cycles: 30
- Mated Height: 17.64mm
- Material - Resin: High-temperature thermoplastic
- Material - Plating: Gold
- Color - Resin: Black
- Operating Temperature Range: -40°C to +105°C
- Contact Material: Brass
- Surface Mount Compatibility: No
- Shrouded: Yes
- Stackable: Yes
- PCB Thickness - Recommended: 1.60mm
- Packaging Type: Tray
- Polarized to PCB: Yes
- RoHS: Compliant
- UL & CSA: Certified
- Flammability Rating: UL 94V-0
Buy the Molex Series Micro-Fit 3.0 Power Connector: 0430450814
Experience reliable power connections with the Molex Micro-Fit 3.0 power connector, designed for high performance, durability, and safety. Featuring a 3.00mm pitch, gold-plated contacts, and a compact dual-row design, it supports fast assembly and secure connections. Certified by UL and CSA, RoHS compliant, and capable of withstanding up to 30 mating cycles, this connector is ideal for industrial, electronics, and power supply applications. Order online now for quick delivery and ensure your projects benefit from top-quality, high-temperature rated interconnect solutions.
Get Molex 0430450814 today—built for precision and long-lasting durability in your power and wiring projects.
Frequently Asked Questions
Where can I buy MOLEX 430450814?
You can click on the BUY or RFQ button to purchase 430450814 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 430450814?
You can download the 430450814 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 430450814?
MOLEX
