MOLEX 431602106 Power Connector
The Molex Sabre Power Connector is a high-current, PCB mount vertical header designed with 6 circuits, glow-wire capable for enhanced fire safety. Made from high-temperature thermoplastic with tin plating, it ensures robust performance in industrial and electronic applications. It features a 1.60mm PCB thickness compatibility, a 7.50mm pitch at mating and termination interfaces, and supports up to 18A and 600V. The connector withstands operating temperatures from -40°C to +75°C, offers high durability with multiple mating cycles, and complies with IEC glow-wire standards for safety. Ideal for power distribution in complex electronic systems.
MOLEX 431602106 Power Connector Specifications:
- Number of Circuits: 6
- Pitch - Mating Interface: 7.50mm
- PCB Thickness - Recommended: 1.60mm
- Current - Maximum per Contact: 18.0A
- Voltage - Maximum: 600V
- Operating Temperature Range: -40°C to +75°C
- Material - Resin: High Temperature Thermoplastic
- Plating Min - Mating & Termination: Tin
- Durability: Up to 50 mating cycles
- Flammability: Glow Wire Capable with GWIT at least 775°C and GWFI above 850°C
- Connector Orientation: Vertical
- Net Weight: 7.064g
- Shrouded: Yes
- Stackable: No
- Process Capability: Lead-free, wave solder compatible
- Maximum Cycles at Max Temperature: 50
- Material - Plating: Tin
Buy the Molex 431602106 – Reliable Power Connector for Industrial Applications
Ensure reliable power connections with the Molex Power Connector. This high-current PCB header features 6 circuits, glow-wire capability for safety, and a compact 7.50mm pitch. Made from high-temperature thermoplastic and tin-plated for corrosion resistance, it supports up to 18A at 600V. Designed for durability with multiple mating cycles, it suits industrial power systems requiring robust and safe connectivity. Purchase online today to experience high performance, safety compliance, and seamless integration in your electronic and industrial projects.
Get Molex 431602106 today—built for precision, high current capacity, and long-lasting durability in industrial power distribution.
