MOLEX 460150602 Power Connector
The Mini-Fit Plus Connector System features a dual-row, vertical header with 6 circuits, designed for wire-to-board applications. Made from high-quality PA Polyamide Nylon 6/6 with UL 94V-0 flammability rating, it features Tin-plated copper alloy contacts rated for 13A per circuit at 600V. The connector is polarized, shrouded, and suitable for operating temperatures from -40°C to +105°C. It is compliant with RoHS, EU ELV, and China RoHS standards, ensuring eco-friendly and safe usage in diverse industrial environments.
MOLEX 460150602 Power Connector Specifications:
- Number of circuits: 6
- Circuit rating: 13A per circuit
- Voltage rating: 600V
- Material: PA Polyamide Nylon 6/6
- Flammability: UL 94V-0
- Contact material: Copper Alloy
- Contact plating: Tin
- Color - Resin: Natural
- Orientation: Vertical
- PC Tail Length: 1.80mm
- PCB Thickness - Recommended: 1.78mm
- Operating temperature range: -40°C to +105°C
- Surface Mount Compatible: No
- Packaging: Tray
- Pitch - Mating Interface: 4.20mm
- Plating min - Mating: 2.540um
- Plating min - Termination: 1.270um
- Lock: No
- Crimp Terminal Compatibility: 45750 Mini-Fit Plus HCS
Buy the Molex 460150602 – Reliable Connector for Industrial Applications
Purchase the Molex Power Connector now and experience exceptional reliability in your industrial and electronic projects. With a 6-circuit design rated for 13A and 600V, this connector withstands harsh environments with a temperature range from -40°C to +105°C. Made from flame-retardant nylon and tin-plated copper contacts, it ensures excellent durability and safe operation. Its polarized, shrouded design simplifies installation and reduces mis-mating risk. Buy online today to secure a high-quality, eco-friendly connector suitable for demanding industrial applications.
Buy Molex 460150602 now and ensure secure, high-current connections with a durable, weather-resistant, and RoHS-compliant connector system for industrial projects.
Frequently Asked Questions
Where can I buy MOLEX 460150602?
You can click on the BUY or RFQ button to purchase 460150602 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 460150602?
You can download the 460150602 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 460150602?
MOLEX
