MOLEX 479502011 Wi-Fi Antenna
The 47950-2011 is a dual-band Wi-Fi antenna operating at 2.4GHz and 5GHz, designed for stand-alone use. It features a 2x2 MIMO configuration with a ground-plane independent, balanced omni-directional design that enhances connectivity and radiates efficiently. The antenna includes a 200mm cable and is suitable for various applications such as consumer electronics, industrial, medical, and communication networking devices. Its adhesive mounting allows easy installation, and its compact size measures approximately 35.90mm x 15.90mm x 0.10mm.
MOLEX 479502011 Wi-Fi Antenna Specifications:
- Frequency Bands: 2.4GHz and 5GHz
- Configuration: 2x2 MIMO
- Design: Ground-plane independent, balanced omni-directional
- Cable Length: 200mm
- Dimensions: approximately 35.90mm x 15.90mm x 0.10mm
- Mounting: Adhesive
- Material: Not specified, RoHS compliant, low-halogen
- Impedance: 50 Ohm
- Radiation Pattern: Omnidirectional
- Peak Gain: 2.6 @ 2.4 GHz, 4.4 @ 5 GHz
- Return Loss: -10 dB typical
- Total Efficiency: >75% @ 5 GHz, >80% @ 2.4 GHz
- Operating Frequency Range: 2400–2483.5 MHz (2.4 GHz), 4900–5900 MHz (5 GHz)
Buy the Molex 0479502011 – Reliable Wi-Fi Antenna for Industrial Applications
Enhance your wireless connectivity with the Molex Wi-Fi antenna designed for reliable dual-band operation at 2.4GHz and 5GHz. Its 2x2 MIMO configuration ensures high data rates and strong signal quality. The omni-directional, ground-plane independent design provides efficient radiation and broad coverage, making it ideal for industrial, medical, communication, and consumer electronics. Easy to install with adhesive mounting, its compact size allows seamless integration into various devices, ensuring robust network performance in demanding environments.
Buy Molex 0479502011 now and experience unmatched reliability and performance with dual-band, omni-directional Wi-Fi connectivity for industrial and consumer devices.
Frequently Asked Questions
Where can I buy MOLEX 479502011?
You can click on the BUY or RFQ button to purchase 479502011 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 479502011?
You can download the 479502011 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 479502011?
MOLEX
